Emotron VS10 - Page 48

48 01-6203-01R3, CG Drives & Automation
Keypad parameter list (short overview of all parameters with display code)
* Default setting depending on the size. Firmware version 04.00.00.00
Display code
Short designation
Default setting
Setting range
Address
Category
P100.00 Output frequency x.x Hz (Read only) 0x2DDD general
P101.00
Scaled act value
x Units
(Read only)
0x400D
general
P102.00
Freq. setpoint
x.x Hz
(Read only)
0x2B0E
general
P103.00
Current actual
x.x %
(Read only)
0x6078
general
P104.00
Motor current
x.x A
(Read only)
0x2D88
general
P105.00 DC-bus voltage x V (Read only) 0x2D87 general
P106.00
Motor voltage
x VAC
(Read only)
0x2D89
general
P107.00
Torque actual
x.x %
(Read only)
0x6077
general
P108.xx
Output power
└ P108.01
Effective power
x.xxx kW
(Read only)
0x2DA2:001
general
└ P108.02 Apparent power x.xxx kVA (Read only) 0x2DA2:002 general
P109.xx
Output energy
└ P109.01
Motor
x.xx kWh
(Read only)
0x2DA3:001
general
└ P109.02
Generator
x.xx kWh
(Read only)
0x2DA3:002
general
P110.xx
AI1 diagnostics
└ P110.01 AI1 terminal % x.x % (Read only) 0x2DA4:001 general
└ P110.02
AI1 scaled freq.
x.x Hz
(Read only)
0x2DA4:002
general
└ P110.03
AI1 scaled PID
x.xx PID unit
(Read only)
0x2DA4:003
general
└ P110.04
AI1 scaled torq.
x.x %
(Read only)
0x2DA4:004
general
└ P110.16
AI1 status
-
(Read only)
0x2DA4:016
general
P111.xx AI2 diagnostics
└ P111.01
AI2 terminal %
x.x %
(Read only)
0x2DA5:001
general
└ P111.02
AI2 scaled freq.
x.x Hz
(Read only)
0x2DA5:002
general
└ P111.03
AI2 scaled PID
x.xx PID unit
(Read only)
0x2DA5:003
general
└ P111.04
AI2 scaled torq.
x.x %
(Read only)
0x2DA5:004
general
└ P111.16 AI2 status - (Read only) 0x2DA5:016 general
P112.xx
AO1 diagnostics
└ P112.01
AO1 Voltage
x.xx V
(Read only)
0x2DAA:001
general
└ P112.02
AO1 Current
x.xx mA
(Read only)
0x2DAA:002
general
P117.xx
Heatsink temp.
└ P117.01 Heatsink temp. x.x °C (Read only) 0x2D84:001 general
P118.00
Digital inputs
-
(Read only)
0x60FD
general
P119.00
Keypad status
-
(Read only)
0x2DAC
general
P120.00
Int. HW states
-
(Read only)
0x2DAD
general
P121.xx
└ P121.01 PID setpoint x.xx PID unit (Read only) 0x401F:001 general
└ P121.02
PID process var.
x.xx PID unit
(Read only)
0x401F:002
general
└ P121.03
PID status
-
(Read only)
0x401F:003
general
P123.00
Mot. i2t utilis.
x %
(Read only)
0x2D4F
general
P125.xx
Inverter diag.
└ P125.01 Active control - (Read only) 0x282B:001 general
└ P125.02
Active setpoint
-
(Read only)
0x282B:002
general
└ P125.03
Keypad LCD stat.
-
(Read only)
0x282B:003
general
└ P125.04
Drive mode
-
(Read only)
0x282B:004
general
└ P125.05
Netw. contr.reg.
-
(Read only)
0x282B:005
general
