Structure of the messages
The following example shows the detailed structure of one of the following messages
(parameter 0x2006:006 ... 0x2006:037):
Message:
00E010431201990000520B0473FC0100050001
00E01043
1201
9900
00520B0473FC0100
0500
01
Meaning:
Diag code
Message type
Text ID
Time stamp in [ns]
Flag param. 1
Parameter 1
Data type: U32 U16 U16 U64 U16 U8
Hex value:
0x4310 E000
0x0112
0x0099
0x0001 FC73 040B 5200
0x0005
0x01
Notes:
• The upper 16 bits of the "Diag Code" contain the error code (in the example "0x4310").
• Bit 0 ... 3 of the message type contain the error type (0: Info, 1: Warning, 2: Trouble, 3:
Fault).
• Convert time stamp: 0x0001 FC73 040B 5200 = 559045896000000 ns = 6 days, 11
hours, 17 minutes, 25 seconds
• The flag for parameter 1 has no meaning for decoding the message.
• The parameter 1 contains the counter for successive, identical events.
