Troubleshooting Picture Image Trouble 152
Confidential
9
Image transfer process
1. Inspect the toner image formed on the drum located
just after the transfer portion (the BTR).
♦Is the toner image on the drum completely copied
onto the paper?.
Go to Step 10
Replace the
BTR ASSY
10
Heat Roll and Pressure Roll
1. Remove the FUSER ASSY. (p.253)
WARNING!: Wait until the Fuser cools, and
then start work.
2. Turn the Gear HR by hand, and inspect the Heat
Roll and the Pressure Roll.
♦Are the Heat Roll and the Pressure Roll free from
scratches, dirt and damage?
See “Parts
below can be
the source of
this error”
Replace the
FUSER ASSY
Step Action and Question Yes No
