Troubleshooting Troubleshooting When There is Error Display 87
Confidential
3.2.20 No Tray/Tray 3, 4 3.2.21 Paper Out/Tray 3, 4
Table 3-23. Troubleshooting for “No Tray/Tray 3, 4”
Step Action and Question Yes No
Parts below can be the source of this error (Chapter 4 Disassembly and Assembly)
• OPT ASSY SIZE (p.306)
• OPTION 550 PAPER FEEDER (p.303)
• Paper Cassette
•HVPS/MCU (p.301)
1
1. Take out the Paper Cassette from the Option 550
Feeder of Tray 3 and Tray 4 once and insert it again.
♦Does the error still occur?
Go to Step 2
Problem
solved
2
Paper Cassette
♦Are the GUIDE END, GEAR SECTOR, RACK
SIZE and LINK SW SIZE1/2/3 of the Paper
Cassette of Tray 3 and Tray 4 installed properly?
Go to 3.4.25
OPT ASSY
SIZE (p.133)
Remount the
part(s) causing
the fault.
Table 3-24. Troubleshooting for “Paper Out/Tray 3, 4”
Step Action and Question Yes No
Parts below can be the source of this error (Chapter 4 Disassembly and Assembly)
• HVPS/MCU (p.301)
•LVPS (p.287)
• SENSOR NO PAPER (p.222), (p.232)
• ACTUATOR NO PAPER (p.223), (p.238)
• OPTION 550 PAPER FEEDER (p.303)
• 550 Paper Cassette (p.191)
• PLATE ASSY BTM (p.330)
• RACK BTM LOCK 550 (p.203)
• HOUSING BASE 550 (p.208)
1
Presence of paper
♦Is there paper in Tray 3 and Tray 4?
Go to Step 2 Supply paper.
2
♦Dose the PLATE ASSY BTM raise properly?
Go to Step3
Reinstall it
properly after
removing the
550 PAPER
CASSETTE.
