EPSON EPL-N3000/AcuLaser M4000N Revision C
Operating Principles Driving Force Trasmission Route 42
Confidential
2.3.3 Duplex Unit
2.3.3.1 Motor Duplex
The driving force for the OPTION DUPLEX is generated by the MOTOR DUPLEX.
The force is transmitted to the OPTION DUPLEX components that require mechanical
driving force, as shown in
Figure. 2-16 and Figure. 2-15 below.
Figure 2-15. Driving Force of Motor Duplex
2.3.3.2 Gear Layout
Figure 2-16. Driving Force Transmission Route for Duplex Unit
2.3.4 OCT
2.3.4.1 Motor Assy OCT
The driving force for the OPTION OCT is generated by the MOTOR ASSY OCT. The
force is transmitted to the OPTION OCT components that require mechanical driving
force, as shown in
Figure. 2-18 and Figure. 2-17 below.
Figure 2-17. Driving Force of Motor Assy OCT
2.3.4.2 Gear Layout
Figure 2-18. Driving Force Transmission Route for OCT
MOTOR DUPLEX
GEAR IDLE 57/37 GEAR IDLE 57/37
GEAR ROLLER GEAR ROLL
GEAR ROLL
GEAR IDLE 77
GEAR IDLE 47
GEAR IDLE 29
GEAR IDLE 29
GEAR IDLE 47
GEAR IDLE 77
GEAR IDLE 57/37
GEAR ROLL
MOTOR DUPLEX
JG6811AA
GEAR 19/37
MOTOR ASSY OCT
GEAR 45
GEAR 19
ROLL OCT LOWER
GEAR 19
ROLL OCT UPPER
GEAR 45
