7.4.3 Engine Status Sheet (AcuLaser M4000N only)
Table 7-7. Engine Status Sheet
Location Item Units Explanation
1 Total Counts Total Pages pages Total number of printed pages
Jam Counts times Number of paper jam occurrences
2 Toner Cartridge Remain % Remaining amount of toner
Total Dots --- Total number of dots
Changes times Number of detections of new toner
cartridges
Capacity pages Remaining toner capacity
Consumed --- Amount of toner consumption
Pages pages Total number of impressions printed
using the cartridge.
3 Fuser Unit Remain % Remaining amount of Fuser Unit.
Pages pages Total number of impressions printed
using the Fuser Unit.
Changes times Number of replacements of new Fuser
Unit.
4 Maintenance
Unit
Remain % The current usage level of the
maintenance unit.
Pages pages Total number of impressions printed
since the unit is installed.
Changes times Number of replacements of
the unit.
5 LC2 Feed
Roller
Consumed % Consumption percentage of the paper
feed roller LC2.
Sheets Sheets Total number of pages printed
since the roller is installed.
Changes Times Number of replacements of
the roller.
6LC3 Feed
Roller
Consumed % Consumption percentage of the paper
feed roller LC2.
Sheets Sheets Total number of pages printed
since the roller is installed.
Changes Times Number of replacements of
the roller.
7 Printer Adjust
Menu
Normal Step The paper type to be notified to the
engine when printing with PaperType =
Normal.
Thick Step The printing speed to be notified to the
engine when printing with PaperType =
Thick.
Extra Thick Step The printing speed to be notified to the
engine when printing with PaperType =
Extra Thick.
Feed Offset mm The offset values specified using the
printer adjustment function.
Scan Offset mm
Feed Offset 2 mm
Scan Offset 2 mm
8 Power On Times Number of power-on times
9 Sleep Times Number of times returned from the
power save mode.
10 MCU --- Engine controller firmwareversion (A
10-digit number).
11 Error Log The following information for each error is printed; panel
messages, EJL status code, the number of printed pages, jam code,
paper size, paper type, date and time. Up to 20 errors are printed in
reverse chronologic order. The target errors are paper jam errors
and service request errors that occurred after (Ready) status.
 JAM : Jam status code is expressed in hexadecimal eight-digit
character string. Table 7-8 “Paper Jam Code,” (p,435) for
explanation on how to read the code.
 Size : Paper size indicated on the control panel
 Type : Paper type name used to be identified by the engine.
 Date/Time : Paper jam occurrence date and time
Table 7-7. Engine Status Sheet
Location Item Units Explanation
