5.1 Adjustment Items
The following table shows the adjustment items required after fixing or replacing certain parts (units).
 EPL-N3000
 AcuLaser M4000N
Note “ * ” : Maintenance unit is composed of the following parts.
• BTR ASSY
• KIT ROLL ASSY FEED X 2 set (For MP Tray and Cassette 1)
Parts Timing Adjustment Item Procedure Required Tools or Program Reference
Fuser Unit After replacing the Fuser Unit with a
new one.
Reset Life Counter Execute "Reset Fuser Counter" in "Reset
Menu".
---
p. 398
BOARD ASSY., MAIN After replacing the BOARD ASSY.,
MAIN with a new one.
Writing USB ID Execute from the special program. PPInitSetting_Ver1x E.exe
p. 399
Parts Timing Adjustment Item Procedure Required Tools or Program Reference
Fuser Unit After replacing the Fuser Unit with a
new one.
Reset Life Counter Execute "Reset Fuser Counter" in "Reset
Menu".
---
p. 398
Maintenance Unit* After replacing the Maintenance Unit
with a new one.
Reset Life Counter Execute "Reset Maintenance Counter" in
"Reset Menu".
---
p. 398
KIT ROLL ASSY FEED
(Cassette 2)
After replacing the KIT ROLL ASSY
FEED (Cassette 2) with a new one.
Reset Life Counter Execute "Reset LC2 Counter" in
"Maintenance Menu".
---
p. 398
KIT ROLL ASSY FEED
(Cassette 3)
After replacing the KIT ROLL ASSY
FEED (Cassette 3) with a new one.
Reset Life Counter Execute "Reset LC3 Counter" in
"Maintenance Menu".
---
p. 398
BOARD ASSY., MAIN After replacing the BOARD ASSY.,
MAIN with a new one.
Writing USB ID Execute from the special program. PPInitSetting_Ver1x E.exe
p. 399
