EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly 150 Paper Cassette 176
Confidential
Installation
1. Install the ROLL ASSY RETARD to the SHAFT RETARD, and secure it with the
hooks.
2. Move the HOLDER RETARD in the direction opposite to the arrow, and install it
to the 150 PAPER CASSETTE.
3. Install the 150 PAPER CASSETTE to the printer body.
C A U T I O N
When installing it, take care not to hold any rubber portion of the
ROLL ASSY RETARD.
C H E C K
P O I N T
Engage the hooks of the ROLL ASSY RETARD with the grooves in
the SHAFT RETARD properly.
C H E C K
P O I N T
After installation, push down the HOLDER RETARD and release
your hand. At this time, make sure that the HOLDER RETARD
returns to the original position by the spring force of the SPRING
RETARD.
