EXTERNAL VIEW AND PART NAMES
Figure 1-1. Front view and Top view
Figure 1-2. Rear View
Table 1-1. Names of Parts
No. Name No. Name
1 face-down tray 7 MP tray
2 top cover 8 standard lower paper cassette
3 locking clip 9 power switch
4 control panel 10 paper support
5 right side cover 11 cover A
6 paper indicator 12 imaging cartridge
1
2
3
4
5
6
7
8
9
10
11
12
Table 1-2. Names of Parts
No. Name No. Name
1 cover B 6 parallel interface connector
2 upper option cover 7 Ethernet interface connector
3 face up tray 8 Type-B interface card slot cover
4 AC inlet 9 paper path lever
5 USB interface connector
1
2
4
5
6
7
8
9
3
6
8
7
