EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly 150 Paper Feeder 216
Confidential
Installation
1. Install the ROLL ASSY GEAR NUDGER to the SHAFT NUDGER, and secure it
with the hook.
2. Install the ROLL ASSY NUDGER to the SHAFT NUDGER, and secure it with
the hook.
3. Install the HOLDER LEFT and ACTUATOR NO PAPER to the SUPPORT
NUDGER.
4. Move the HOLDER LEFT in the direction opposite to the arrow, and secure it to
the 150 FEEDER ASSY with the three hooks.
C A U T I O N
 When installing the ROLL ASSY NUDGER or ROLL ASSY
GEAR NUDGER, take care not to hold its rubber portion.
 Engage the hooks of the ROLL ASSY GEAR NUDGER with
the grooves in the SHAFT NUDGER properly.
C A U T I O N
Engage the hooks of the ROLL ASSY NUDGER with the grooves in
the SHAFT NUDGER properly.
C A U T I O N
 Securely fit the shafts on both ends of the ACTUATOR NO
PAPER into the HOLDER LEFT and SUPPORT NUDGER.
 Hitch the hook of the ACTUATOR NO PAPER on the
HOLDER LEFT.
C H E C K
P O I N T
After installation, operate the ACTUATOR NO PAPER with your
finger and make sure that it moves properly.
