EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly 550 Paper Feeder 237
Confidential
Installation
1. Move the GUIDE TRAY LEFT in the directions opposite to the arrows (A), (B),
and install it to the frame.
2. Install the GUIDE TRAY LEFT with the six screws (gold, tapping, 8mm x1, gold,
6mm x5).
3. Connect the HARNESS ASSY LVPS to the connector (P/J1821) of the GUIDE
TRAY LEFT.
4. Return the printer body to the normal position.
5. Install the COVER FRONT. (p.172)
6. Install the COVER TOP, CONTROL PANEL. (p.170)
7. Install the 500 EXIT ASSY. (p.262)
8. Install the COVER EXIT 500. (p.261)
9. Install the COVER RIGHT. (p.168)
10. Install the COVER LEFT. (p.169)
11. Install the FUSER ASSY. (p.253)
12. Install the COVER REAR. (p.167)
13. Install the COVER REAR 500. (p.270)
14. Install the Imaging Cartridge and Paper Cassette.
C A U T I O N
In the place of the Screw (A) in the figure, tighten the screw (gold,
tapping, 8mm).
(Refer to Figure 4- 56)
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
