EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Xero 244
Confidential
Installation
1. Move and install the SHIELD PLATE ROS in the direction opposite to the arrow.
2. Secure the SHIELD PLATE ROS to the frame with the two screws (black, with
collars, 8mm).
3. Install the ROS ASSY. (p.239)
4. Install the FUSER ASSY. (p.253)
5. Install the DUCT FRONT, FAN SUB. (p.241)
6. Install the COVER FRONT. (p.172)
7. Install the COVER TOP, CONTROL PANEL. (p.170)
8. Install the 500 EXIT ASSY. (p.262)
9. Install the COVER EXIT 500. (p.261)
10. Install the COVER RIGHT. (p.168)
11. Install the COVER LEFT. (p.169)
12. Install the COVER REAR. (p.167)
13. Install the COVER REAR 500. (p.270)
C A U T I O N
Never give impact to the ROS ASSY with a screwdriver or the like.
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
