EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Xero 246
Confidential
Installation
1. Install the GUIDE CRU LEFT to the frame.
2. Secure the GUIDE CRU LEFT with the three screws (gold, 6mm).
3. Connect the connector (P/J46 and P/J47) of the HARNESS ASSY FUSER to the
LVPS.
4. Connect the connector (P/J45) of the INTERLOCK S/W 24V to the LVPS.
5. Connect the connector (P/J141) of the INTERLOCK S/W 5V to the HARNESS
ASSY LVPS.
6. Secure the HARNESS ASSY FUSER, coming out of the GUIDE CRU LEFT, to
the frame with the clamp.
7. Connect the connector (P/J4647) of the HARNESS ASSY FUSER to the frame.
8. Install the SHIELD PLATE LVPS. (p.285)
9. While lifting the 150 FEEDER ASSY, install the MOTOR COVER. (p.277)
10. Install the SHIELD PLATE ROS. (p.243)
11. Install the ROS ASSY. (p.239)
12. Install the DUCT FRONT, FAN SUB. (p.241)
13. Install the GUIDE TRAY LEFT. (p.236)
14. Install the BTR ASSY. (p.254)
15. Install the FUSER ASSY. (p.253)
16. Install the COVER FRONT. (p.172)
17. Install the COVER TOP, CONTROL PANEL. (p.170)
18. Install the 500 EXIT ASSY. (p.262)
19. Install the COVER EXIT 500. (p.261)
20. Install the COVER RIGHT. (p.168)
21. Install the COVER LEFT. (p.169)
22. Install the COVER REAR. (p.167)
23. Install the COVER REAR 500. (p.270)
C A U T I O N
When installing the GUIDE CRU LEFT, make sure that the
LEVER LINK is mounted on the GUIDE CRU LEFT.
C H E C K
P O I N T
After securing the GUIDE CRU LEFT with the three screws, pull
up the LEVER LINK. At this time, confirm with your finger that
the LINK GEAR 3 retracts.
C A U T I O N
Never give impact to the ROS ASSY with a screwdriver or the like.
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
