EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Xero 260
Confidential
Installation
1. Combine the LEVER LINK and LINK GEAR 3 as shown in the figure, and install
the combination to the GUIDE CRU LEFT.
2. Install the COVER GUIDE CRU and HARNESS ASSY FUSER to the GUIDE
CRU LEFT.
(p.251)
3. Install the GUIDE CRU LEFT to the frame. (p.245)
4. Install the SHIELD PLATE LVPS. (p.285)
5. Install the MOTOR COVER. (p.277)
6. Install the GUIDE TRAY LEFT. (p.236)
7. Install the SHIELD PLATE ROS. (p.243)
8. Install the ROS ASSY. (p.239)
9. Install the DUCT FRONT, FAN SUB. (p.241)
10. Install the COVER FRONT. (p.172)
11. Install the COVER TOP, CONTROL PANEL. (p.170)
12. Install the 500 EXIT ASSY. (p.262)
13. Install the COVER EXIT 500. (p.261)
14. Install the COVER RIGHT. (p.168)
15. Install the COVER LEFT. (p.169)
16. Install the FUSER ASSY. (p.253)
17. Install the COVER REAR. (p.167)
18. Install the COVER REAR 500. (p.270)
19. Install the BTR ASSY. (p.254)
C H E C K
P O I N T
 When installing the GUIDE CRU LEFT, make sure that the
LEVER LINK is mounted on the GUIDE CRU LEFT.
 After installing the GUIDE CRU LEFT, pull up the LEVER
LINK. At this time, confirm with your finger that the LINK
GEAR 3 retracts.
(Refer to Figure 4- 62)
C A U T I O N
Never give impact to the ROS ASSY with a screwdriver or the like.
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
