EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Frame & Drive 278
Confidential
Installation
1. Install the MOTOR COVER to the frame with the one screw (silver, 6mm).
2. Connect the harness of the MAIN MOTOR to the clamp.
3. Install the SHIELD PLATE ROS. (p.243)
4. Install the ROS ASSY. (p.239)
5. Install the DUCT FRONT, FAN SUB. (p.241)
6. Install the GUIDE TRAY LEFT. (p.236)
7. Install the COVER FRONT. (p.172)
8. Install the COVER TOP, CONTROL PANEL. (p.170)
9. Install the 500 EXIT ASSY. (p.262)
10. Install the COVER EXIT 500. (p.261)
11. Install the COVER RIGHT. (p.168)
12. Install the COVER LEFT. (p.169)
13. Install the FUSER ASSY. (p.253)
14. Install the COVER REAR. (p.167)
15. Install the COVER REAR 500. (p.270)
16. Install the BTR ASSY. (p.254)
C A U T I O N
Never give impact to the ROS ASSY with a screwdriver or the like.
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
