EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Frame & Drive 282
Confidential
Installation
1. Install the GEAR ASSY HOUSING to the frame.
2. Install the GEAR ASSY HOUSING to the frame with the six screws (silver, 6mm
x5, gold, 6mm x1).
3. Secure the HARNESS ASSY INTERLOCK 2 and HARNESS ASSY LVPS with
the clamps of the GEAR ASSY HOUSING.
4. Install the COVER LEFT. (p.169)
5. Install the COVER REAR. (p.167)
6. Install the COVER REAR 500. (p.270)
C A U T I O N
When the GEAR ASSY HOUSING is removed, two of the gears
mounted on the GEAR ASSY HOUSING may come off as they are
not secured. Be careful not to drop these gears.
C H E C K
P O I N T
During installation, assemble so that the gears of the GEAR ASSY
HOUSING, MAIN MOTOR and GEAR ASSY PLATE engage with
each other securely, and make confirmation after the work. Open
the COVER OPEN, and assemble while turning the MAIN
MOTOR by hand to make the gears engage easily with each other.
C A U T I O N
In the place of the Screw (A) in the figure, tighten the screw of gold,
6mm.
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
