EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Electrical 292
Confidential
Installation
1. Install the INTERLOCK S/W REAR to the frame with the one screw (silver,
6mm).
2. Secure the HARNESS ASSY INTERLOCK 2 of the INTERLOCK S/W REAR
with the clamp of the GEAR ASSY HOUSING.
3. Connect the connector (P/J44) of the INTERLOCK S/W REAR to the LVPS.
4. Install the SHIELD PLATE LVPS. (p.285)
5. Install the COVER FRONT. (p.172)
6. Install the COVER TOP, CONTROL PANEL. (p.170)
7. Install the 500 EXIT ASSY. (p.262)
8. Install the COVER EXIT 500. (p.261)
9. Install the COVER RIGHT. (p.168)
10. Install the COVER LEFT. (p.169)
11. Install the COVER REAR. (p.167)
12. Install the COVER REAR 500. (p.270)
C A U T I O N
When installing it, pull the lever of the CHUTE EXIT FUSER.
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
