EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Option Duplex 358
Confidential
Installation
1. Install the SWITCH DUPLEX to the BRACKET MOTOR, and secure it with the
hooks.
2. Connect the HARNESS ASSY DUP COVER to the connector (P/J52) of the
SWITCH DUPLEX.
3. Install the BRACKET MOTOR to the COVER HSG DUP with the three screws
(gold, tapping, 8mm).
4. Install the SPRING LATCH between the BRACKET MOTOR and LEVER
LATCH LEFT.
5. Install the HARNESS ASSY DUP EARTH with the one screw (silver, 6mm).
6. Install the PWBA DUPLEX. (p.347)
7. Install the COVER TOP. (p.346)
8. Install the COVER LEFT. (p.353)
C H E C K
P O I N T
When installing the BRACKET MOTOR, be careful not to mislay
the gears.
C A U T I O N
When installing the PWBA DUPLEX, pay attention to its
installation orientation.
C H E C K
P O I N T
When installing the COVER TOP, match its positioning holes with
the bosses of the COVER HSG DUP.
C H E C K
P O I N T
When installing the COVER LEFT, match its positioning holes
with the bosses of the COVER HSG DUP.
