EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Option OCT 361
Confidential
Installation
1. Insert the two hooks at the bottom of the COVER OCT into holes of the printer
body, place the Option OCT on the printer body, and connect it to the connector
(P/J3070) of the HARNESS ASSY OCT2 of the printer body.
2. Tighten the two SCREWs THUMB to secure the Option OCT to the printer body.
3. Disengage the hinges at both ends of the FLAPPER L from the COVER OCT.
C A U T I O N
During installation, do the work carefully not to drop the Option
OCT.
C H E C K
P O I N T
When installing the Option OCT, securely insert the two hooks at
its bottom into the printer body.
C H E C K
P O I N T
When installing the Option OCT, fix it tightly by securely
tightening the SCREWs THUMB.
