Installation
1. Install the COVER OCT to the printer body.
2. Secure the COVER OCT to the printer body with the 2 bottom screws (gold,
tapping, 8mm).
3. Secure the COVER OCT to the printer body with the 2 rear screws (gold, tapping,
8mm).
4. Insert and install the LINK mounted to the FLAPPER R into the ACTUATOR
FULL STACK diagonally from the bottom, and then install the hinges at both ends
of the FLAPPER R to the COVER OCT.
5. Similarly, insert and install the LINK mounted to the FLAPPER L into the SHAFT
FULL STACK diagonally from the bottom, and then install the hinges at both ends
of the FLAPPER L to the COVER OCT.
6. Install the WIGHT.
7. Install the COVER REAR. (p.362)
C H E C K
P O I N T
After installation, move the FLAPPER L and make sure that the
ACTUATOR FULL STACK operates synchronously. At the same
time make also sure that the FLAPPER R moves smoothly.
