EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Option OCT 369
Confidential
Installation
1. Install the PWBA OCT to the SUPPORT OCT RIGHT with the one screw (silver,
6mm).
2. Install the SUPPRT OCT RIGHT mounted with the PWBA OCT to the printer
body with the two screws (gold, tapping, 8mm).
3. Connect the harness connectors to the connectors (P/J70, P/J71, P/J72, P/J73, P/
J74, P/J75) of the PWBA OCT.
4. Clamp the harnesses connected to the S/W REAR COVER.
5. Install the COVER FRONT. (p.366)
6. Install the COVER OCT. (p.364)
7. Install the COVER REAR. (p.362)
C H E C K
P O I N T
 When installing it, insert the PWBA OCT into the two guide
grooves of the printer body.
 When installing it, insert the SHUTTER part of the
ACTUATOR FULL STACK into the photo interrupter part on
the PWBA OCT.
C H E C K
P O I N T
When connecting the harness connectors, insert the connectors by
securing the PWBA OCT by hand.
