EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Option OCT 375
Confidential
Installation
1. Move and install the ROLL OCT LOWER in the direction opposite to the arrow.
2. Install the BEARING ROLL on the GEAR 19 side.
3. Install the GEARs 19, GEARs 45, and GEAR 19/37 in this order.
4. Install the BRACKET MOTOR OCT with the two screws (gold, tapping, 8mm).
5. Install the SUPPORT OCT LEFT with the two screws (gold, tapping, 8mm).
6. Install the COVER OCT. (p.364)
7. Install the COVER REAR. (p.362)
C A U T I O N
When installing the ROLL OCT LOWER, be careful not to hold its
rubber portion.
C A U T I O N
Install the GEARs 19 in the correct orientation.
