EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly AcuLaser M4000N Unique Disassembly Procedures 381
Confidential
Installation
1. Install the OPERATION PANEL to the COVER TOP, and secure it with the two
hooks.
2. Connect the connector (P/J1) of the OPERATION PANEL.
3. Route the harness of CONTROL PANEL through the two hooks of the COVER
TOP.
4. Install the COVER TOP to the printer body, and secure it to the COVER FRONT
with the two hooks at the front of the COVER TOP.
5. Engage the boss of the COVER OPEN with the hole of the LEVER LINK.
6. Install the COVER TOP to the frame with the two screws (silver, with collars,
8mm).
7. Install the 500 EXIT ASSY. (p.262)
8. Install the COVER EXIT 500. (p.261)
9. Install the COVER RIGHT. (p.168)
10. Install the COVER LEFT. (p.169)
11. Install the COVER REAR (AcuLaser M4000N). (p.379)
12. Install the COVER REAR 500. (p.270)
C A U T I O N
Engage the boss of the COVER OPEN with the hole of the LEVER
LINK, with the COVER OPEN open and the LEVER LINK
extended.
C A U T I O N
When installing it, pass the harnesses of the MOTOR ASSY EXIT
and HARNESS ASSY EXIT SNR1 through the hole of the frame.
