EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly AcuLaser M4000N Unique Disassembly Procedures 389
Confidential
Installation
1. Install the MAIN MOTOR to the frame with the three screws (gold, 6mm).
2. Connect the connector (P/J271) of the MAIN MOTOR to the relay connector.
3. Connect the connector (P/J43) of the MAIN MOTOR to the LVPS.
4. Install the SHIELD PLATE LVPS. (p.285)
5. Install the MOTOR COVER. (p.277)
6. Install the GUIDE TRAY LEFT. (p.236)
7. Install the SHIELD PLATE ROS. (p.243)
8. Install the ROS ASSY (AcuLaser M4000N). (p.386)
9. Install the DUCT FRONT, FAN SUB. (p.241)
10. Install the COVER FRONT. (p.172)
11. Install the COVER TOP, CONTROL PANEL (AcuLaser M4000N). (p.380)
12. Install the 500 EXIT ASSY. (p.262)
13. Install the COVER EXIT 500. (p.261)
14. Install the COVER RIGHT. (p.168)
15. Install the COVER LEFT. (p.169)
16. Install the FUSER ASSY. (p.253)
17. Install the COVER REAR (AcuLaser M4000N). (p.379)
18. Install the COVER REAR 500. (p.270)
19. Install the BTR ASSY. (p.254)
C A U T I O N
Never give impact to the ROS ASSY with a screwdriver or the like.
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
