Abbreviation
This manual uses original abbreviations, in addition to general abbreviations.
Typical abbreviations are as follows:
AG ...............................................Analog Ground
ASSY....................................................Assembly
B/W............................................ Black and White
BCR.......................................... Bias Charge Roll
Bk ............................................................... Black
BTR .........................................Bias Transfer Roll
BUR................................................ Back Up Roll
CCW.................................... Counter Clock Wise
CRU......................... Customer Replaceable Unit
CRUM............................................. CRU Monitor
CST .......................................................Cassette
CW..................................................... Clock Wise
DIAG................................................... Diagnostic
dpi....................................................dots per inch
DTS ..................................................Detack Saw
ELEC. ...................................................... Electric
EP.........................................Electrophotography
FDR ..........................................................Feeder
FG.................................................Frame Ground
GND......................................................... Ground
H/R ....................................................... Heat Roll
Hex ................................................. Hexadecimal
HVPS....................... High Voltage Power Supply
I/F .......................................................... Interface
I/L............................................................Interlock
ID...................... Image Density (or Identification)
L..................................................................... Left
L/H........................................................Left Hand
L/P ......................................................Low Paper
LD.....................................................Laser Diode
LEF............................................Long Edge Feed
LVPS ........................ Low Voltage Power Supply
MAG......................................................Magnetic
MCU...................................Machine Control Unit
MOT. .......................................................... Motor
N/P ....................................................... No Paper
NVM ................................... Non Volatile Memory
OCT......................................... Offset Catch Tray
OHP ..................................... Overhead Projector
(In this manual, OHP means OHP film)
OPT..................................... Optional Paper Tray
P/H ..............................................Paper Handling
P/R .................................................Pressure Roll
Pixel .................................................. Picture Cell
PPM .........................................Prints Per Minute
PV ...................................................Print Volume
PWB................................... Printed Wiring Board
R.................................................................. Right
R/H.....................................................Right Hand
REGI. ............................................... Registration
ROS ................................Raster Output Scanner
RTN...........................................................Return
SEF .......................................... Short Edge Feed
SG.................................................Signal Ground
SNR.......................................................... Sensor
SOL........................................................Solenoid
SOS................................................ Start Of Scan
SPI .............................................. Scans Per Inch
SSI .....................................Single Sheet Inserter
SW ............................................................Switch
TEMP. .............................................Temperature
TR .......................................................... Transfer
TRANS................................................. Transport
XERO............................................... Xerographic
