EPSON EPL-N3000/AcuLaser M4000N Revision C
Troubleshooting Troubleshooting When There is Error Display 80
Confidential
5
ROLL ASSY RETARD
1. Check the ROLL ASSY RETARD installed on
each Paper Cassette.
♦Is the ROLL ASSY RETARD clean and installed
normally?
Go to Step 6
Replace the
ROLL ASSY
RETARD
6
Test Printing
1. Feed paper from Tray 1 or Tray 2 to execute test
printing.
2. When there is an optional feeder, feed paper from
Tray 3 or Tray 4 to execute test printing.
♦Does the error occur?
Go to Step 7 Problem solved
7
Position of paper
1. Remove the Imaging Cartridge.
♦Is the leading edge of paper in contact with the
ACTUATOR B of the SENSOR REGI?
Go to Step 8
Go to 3.4.5
SENSOR REGI
(p.117)
8
Paper feed tray
1. Check the paper feed tray during execution of test
printing.
♦Was paper fed from the Tray 1 or Tray 2?
Go to Step 9 Go to Step 10
9
CHUTE ASSY FDR1/2
1. Turn each gear and roller of the CHUTE ASSY
FDR1/2 by hand.
♦Does each gear and roller turn smoothly?
Go to Step 10
Replace the
CHUTE ASSY
FDR1/2
10
Paper feed tray
1. Check the paper feed tray during execution of test
printing.
♦Was paper fed from the Tray 3 or Tray 4?
Go to Step 11
Check that paper
has been set, and
then go to Step 8
11
550 FEEDER OPTION
1. Turn each gear or roller of the 550 FEEDER
OPTION by hand.
♦Does each gear or roller turn smoothly?
Go to Step 12
Replace the
OPTION 550
PAPER
FEEDER
12
ROLL ASSY TURN
1. Turn the ROLL ASSY TURN by hand.
♦Does the ROLL ASSY TURN turn smoothly?
Replace the
HVPS/MCU
Replace ROLL
ASSY TURN
Table 3-13. Troubleshooting for “Paper Jam/Tray to Regi” (continued)
Step Action and Question Yes No
