5.7 Judging Measurement Results (Comparator Function)
203
5
Chapter 5 ANALYZER Function
When the segment function is enabled, a different judgment area can be set for each segment.
When the setting is
Judgment Area Setting
Sets the upper and lower limit values
based on the current measurement
values.
Sets the reference value, upper limit
value, and lower limit value.
Sets the upper and lower limit values
as percentage values relative to the
reference value.
Sets the upper and lower limit values
as absolute values relative to the refer-
ence value.
When you want to cancel the setting:
Press .
Judgment Area Setting
2. Use or to select the segment for which
you want to set the judgment area.
3. Press .
1. Set the judgment area.
