8.3 Self Checks (Self Diagnosis)

308

You can perform position compensation of the touch panel.

Panel Compensation

LCR Initial Screen

1

Self Checks

3

Panel Compensation

Press in the location of continuously

until the green appears.

Press .

2

Self Checks

Procedure

This operation is possible in any of the mode, mode.
