11.1 External Input/Output Connector and Signals
365
11
Chapter 11 External Control
Pin
I/O
LCR Mode ANALYZER Mode
Logic
Signal name Function Signal name Function
1INTRIG
External trigger TRIG External trigger
Pos
Edge
2 - (Unused) - (Unused) - - -
3 - (Unused) - (Unused) - - -
4INLD1
Select panel number LD1 Select panel number
Neg
Level
5INLD3 Select panel number LD3 Select panel number
Neg
Level
6INLD5 Select panel number LD5 Select panel number
Neg
Level
7 - (Unused) - (Unused) - - -
8 - ISO_5V Isolated 5 V power
output
ISO_5V Isolated 5 V power output - -
9 - ISO_COM Isolated common sig-
nal ground
ISO_COM Isolated common signal ground - -
10 OUT ERR
Measurement fault ERR Measurement fault
Neg
Level
11 OUT BIN1, PARA1-HI BIN judgment results
Comparator judgment
results of the first pa-
rameter
PARA1-HI
,
PARA1_LMAX_MEASNG
Analyzer comparator results of the first
parameter in AREA mode
(Output if even one HI judgment)
Analyzer comparator results for the local
maximum value of the first parameter in
PEAK mode
(Output if the vertical axis (measurement
value) is out of the range or there is no
comparison peak)
Neg
Level
12 OUT BIN3, PARA1-LO BIN judgment results
Comparator judgment
results of the first pa-
rameter
PARA1-LO
,
PARA1_LMAX_CONDNG
Analyzer comparator results of the first pa-
rameter in AREA mode
(Output if even one LO judgment)
Analyzer comparator results for the local
maximum value of the first parameter in
PEAK mode
(Output if the horizontal axis (sweep setting)
is out of the range or there is no comparison
peak)
Neg
Level
13 OUT BIN5, PARA3-IN BIN judgment results
Comparator judgment
results of the third pa-
rameter
PARA2-IN
,
PARA2_LMAX_IN
Analyzer comparator results of the sec-
ond parameter in AREA mode
(Output if all judgment results are IN)
Analyzer comparator results for the local
maximum value of the second parameter
in PEAK mode
(Output if PEAK is IN)
Neg
Level
14 OUT BIN7, AND BIN judgment results
Comparator judgment
results AND
AND
Comparator judgment result AND
Neg
Level
15 OUT BIN9 BIN judgment results PARA1_LMIN_IN Analyzer comparator results for the local
minimum value of the first parameter in
PEAK mode
(Output if PEAK is IN)
Neg
Level
16 OUT (Unused) - PARA2_LMIN_MEASNG Analyzer comparator results for the local
minimum value of the second parameter
in PEAK mode
(Output if the vertical axis (measurement
value) is out of the range or there is no
comparison peak)
Neg
Level
17 OUT (Unused) - PARA2_LMIN_CONDNG Analyzer comparator results for the local
minimum value of the second parameter in
PEAK mode
(Output if the horizontal axis (sweep setting)
is out of the range or there is no comparison
peak)
Neg
Level
18
-
(Unused) - (Unused) - - -
To Next Page
