11.1 External Input/Output Connector and Signals
366
19 OUT OUT_OF_BINS BIN judgment results CIRCUIT_NG Equivalent circuit analysis comparator
judgment result output (output when log-
ical AND of judgment results is FAIL)
Neg
Level
20 - (Unused) - (Unused) - - -
21 IN CALIB
DC adjustment request
(Unused) -
Neg
Level
22 IN LD0 Select panel number LD0 Select panel number
Neg
Level
23 IN LD2
Select panel number LD2 Select panel number
Neg
Level
24 IN LD4 Select panel number LD4 Select panel number
Neg
Level
25 IN LD6
Select panel number LD6 Select panel number
Neg
Level
26 IN LD_VALID
Execute panel load LD_VALID Execute panel load
Neg
Level
27 - ISO_COM Isolated common sig-
nal ground
ISO_COM Isolated common signal ground - -
28 OUT EOM
End of measurement EOM End of measurement
Neg
Edge
29 OUT INDEX Analog measurement
finished
INDEX Analog measurement finished
Neg
Edge
30 OUT BIN2, PARA1-IN BIN judgment results
Comparator judgment
results of the first pa-
rameter
PARA1-IN
,
PARA1_LMAX_IN
Analyzer comparator results of the first
parameter in AREA mode
(Output if all judgment results are IN)
Analyzer comparator results for the local
maximum value of the first parameter in
PEAK mode
(Output if PEAK is IN)
Neg
Level
31 OUT BIN4
, PARA3-HI BIN judgment results
Comparator judgment
results of the third pa-
rameter
PARA2-HI
,
PARA2_LMAX_MEASNG
Analyzer comparator results of the sec-
ond parameter in AREA mode
(Output if even one HI judgment)
Analyzer comparator results for the local
maximum value of the second parameter
in PEAK mode
(Output if the vertical axis (measurement
value) is out of the range or there is no
comparison peak)
Neg
Level
32 OUT BIN6
, PARA3-LO BIN judgment results
Comparator judgment
results of the third pa-
rameter
PARA2-LO
,
PARA2_LMAX_CONDNG
Analyzer comparator results of the second
parameter in AREA mode
(Output if even one LO judgment)
Analyzer comparator results for the local
maximum value of the second parameter in
PEAK mode
(Output if the horizontal axis (sweep setting)
is out of the range or there is no comparison
peak)
Neg
Level
33 OUT BIN8
BIN judgment results PARA1_LMIN_MEASNG Analyzer comparator results for the local
minimum value of the first parameter in
PEAK mode
(Output if the vertical axis (measurement
value) is out of the range or there is no
comparison peak)
Neg
Level
34 OUT BIN10
BIN judgment results PARA1_LMIN_CONDNG Analyzer comparator results for the local
minimum value of the first parameter in
PEAK mode
(Output if the horizontal axis (sweep setting)
is out of the range or there is no comparison
peak)
Neg
Level
35 OUT (Unused) - PARA2_LMIN_IN
Analyzer comparator results for the local
minimum value of the second parameter
in PEAK mode
(Output if PEAK is IN)
Neg
Level
36 - (Unused) - (Unused) - - -
37 - (Unused) - (Unused) - - -
Pin
I/O
LCR Mode ANALYZER Mode
Logic
Signal name Function Signal name Function
