13.1 General Specifications
391
13
Chapter 13 Specifications
Panel save and load
function
LCR mode (single frequency): 30 different measurement conditions can be saved.
Sweep measurement: 2 different measurement conditions can be saved.
Compensation value only: 128 different measurement conditions can be saved.
Any measurement condition can be load by key operation or a control signal via the EXT I/O.
Memory function 32,000 measurement result items can be saved to the instrument.
(Reading via RS-232C, GP-IB, USB, and LAN is possible.)
Contact check (1) 4-terminal contact check (only when low Z high accuracy mode 100 m range, 1 range)
Performs a contact (disconnection) check between H
CUR
and H
POT
and between L
CUR
and L
POT
.
When the current monitor value is 0.1 mA or less, a contact error is output.
(2) HIGH-Z reject function (detection of OPEN state during 2-terminal measurement)
When the measurement value is higher than the judgment reference, a contact error is
output.
Judgment reference: The impedance Z value can be set to between 0 to 30,000% of the
measurement range.
Error output: An error is output from the EXT I/O.
(3) Detection level monitoring function
Detects a contact error (chattering detection).
A comparison is made with the effective value of the first waveform that is acquired, and
a contact error is output when a variation in the effective value of a subsequent waveform
exceeds the judgment reference.
Judgment reference: 0.01% to 100.00% (0.01% resolution) relative to the reference value
can be set.
Error output: An error is displayed on the LCD and output from the EXT I/O.
Print function The measurement values and graph can be printed.
* Requires a printer that supports RS-232C communications.
Buzzer sound The buzzer for the comparator judgment result (IN or NG) can be set to ON/ OFF.
The buzzer sound for key input can be set to ON/ OFF.
2.Function
3.Interface
Display 5.7-inch color TFT
Handler interface Equipped as standard
RS-232C interface Equipped as standard
GP-IB interface Equipped as standard
USB(HI SPEED) interface Equipped as standard
Full-Speed/Hi-Speed supported
LAN interface Equipped as standard
10BASE-T/100BASE-TX
USB flash drive The measurement conditions, measurement values, and screen can be saved.
The measurement conditions can be load.
Saved measurement values and screens can be displayed.
File deletion, folder creation, and disk formatting
