Chapter 7 AutoTest Mode
AutoTests Tab
118 DSAM Help User Guide Rev. 001
6 Press ENTER.
7 Using the arrow keys, select an option.
8 Press ENTER.
9 Using the arrow keys, select Limit Plan.
10 Press ENTER.
11 Using the arrow keys, select an option.
12 Press ENTER.
13 Press the Settings softkey.
14 Using the arrow keys, select the following options:
– Edit Test Point Compensation – See page 71.
– Edit MAC Address – See page 65.
– Edit AutoTest Settings – When the select an AutoTest screen is
displayed, use the arrow keys to select one of the following
options then press the Configure softkey.
– Video Channels – See “Configuring AutoTest for Video Chan-
nels” on page 89.
– Cable Modem – See “Configuring AutoTest for Cable Modem”
on page 88.
15 Press ENTER.
NOTE
To perform the test without checking the results against limit values,
select Off.
If you select Off as the limit plan value, no pass/fail information is
displayed in the test results.
NOTE
Use “Regional Preferences” on page 43 to specify the type of signal
level units and digital performance units to display.
Use “Limit Sets” on page 58 to edit limit set parameters to meet
your needs.
Use “Other Settings” on page 65 to define the best measurement
settings (such as DOCSIS settings) for your current work practices.
21128026 R001 DSAM Help User Guide.book Page 118 Thursday, February 5, 2009 2:02 PM
