Chapter 5 Configuring the Meter
Configure – Measure Tab
DSAM Help User Guide Rev. 001 59
7 Using the arrow keys, select the parameter you want to edit.
8 Press ENTER.
9 Using the arrow keys and the alphanumeric keypad, edit the
value.
10 Press ENTER.
11 Press ENTER.
12 Press the OK softkey.
13 Press the Done softkey.
Figure 50 Configure – Edit Cable Modem
NOTE
If a “key” icon is displayed to the left of a limit set, it indicates that
the limit set is locked and requires a PIN entry prior to editing.
To reset the currently selected parameter to its factory default value,
press the Default softkey.
Table 22 Limit Set Parameters
Name Description
Min Video Level The minimum video signal level before it exceeds
your set limit. The default value is 0.0.
Max Video Level The maximum video signal level before it exceeds
your set limit. The default value is 15.0.
21128026 R001 DSAM Help User Guide.book Page 59 Thursday, February 5, 2009 2:02 PM
