Chapter 8 Measure Mode – Basic Tab
Full Scan
DSAM Help User Guide Rev. 001 161
5 dB/div or 10 dB/div – Enables you to adjust the vertical resolu-
tion of the graph for the best viewing.
Graph (default)/Table – Displays the measurements in graph or
table form. Measurements are continually updated in this graph
view, but static in table view.
Single Channel – Displays the measurements one channel at a
time.
Tilt – Displays the Tilt screen.
Full Scan – Displays the Full Scan screen.
Pause (Shift, 8) – Suspends measurement updates.
3 Press ENTER.
Full Scan
Full Scan measurement displays the carrier levels of the entire
channel plan (up to 999 channels at a time) and displays the audio and
video levels of a carrier on a single screen. You can view results in
graph or table form and results can be measured in relation to user-
defined limit sets. Results can also be stored for later reference.
Running a Full
Scan
To run a Full Scan
1 Press Measure.
2 Press the Basic softkey.
NOTE
For best reference setting results you may need to press the Auto
Reference button up to three times.
21128026 R001 DSAM Help User Guide.book Page 161 Thursday, February 5, 2009 2:02 PM
