Chapter 9 Measure Mode – Service Tab
DOCSIS
DSAM Help User Guide Rev. 001 221
3 Using the arrow keys, select the IP address you want to edit.
4 Press ENTER.
5 Press the Settings softkey.
6 Using the arrow keys, select Modify IP.
7 Press ENTER.
8 Using the arrow keys and the alphanumeric keypad, edit the IP
address.
9 Press the OK softkey.
Deleting Ping IP
Addresses
To delete an IP address
1 Using the arrow keys, select IP Address.
2 Press ENTER.
3 Using the arrow keys, select the IP address you want to delete.
4 Press ENTER.
5 Press the Settings softkey.
6 Using the arrow keys, select Delete IP.
7 Press ENTER.
Viewing
VoIPCheck
Results
The VoIPCheck CMTS Loop test (additional purchase required)
displays VoIP call statistics without MTA provisioning. The VoIPCheck
CMTS Loop test is a continuous test. During a VoIPCheck, packet
loss, jitter, delay, R-Value and MOS values are displayed in table
format.
NOTE
The last edited IP address is placed on the top of the option list.
NOTE
Since you can only run VoIPCheck after the meter has successfully
ranged and registered with the CMTS and the MTAs have success-
fully initialized, results are not available if Ranging Only is set in the
DOCSIS Configuration field (“Configuring DSAM for DOCSIS Tests”
on page 205) or if the DSAM failed to register with the CMTS.
21128026 R001 DSAM Help User Guide.book Page 221 Thursday, February 5, 2009 2:02 PM
