Chapter 9 Measure Mode – Service Tab
VoIP
242 DSAM Help User Guide Rev. 001
Selecting the
Settings Softkey
Options
To select the Settings softkey options
1 To display the Downstream Plans screen, use the arrow keys and
select Channel Plans.
2 Press ENTER.
OR
3 To display the Adjust Sounds screen, use the arrow keys and
select Audio.
4 Press ENTER.
Viewing VoIP MOS
Results
R-Value Listening, R-Value Conversational, MOS Listening, and MOS
Conversational values are computed using the packet loss, jitter and
delay results. These values are intended to give a quantitative assess-
ment of the call quality. The VoIP MOS screen enables you to place
and receive calls and measure these values.
To view VoIP MOS results
1 Press the View softkey.
2 Using the arrow keys, select Call.
3 Press ENTER.
NOTE
The limit set parameters you define remain constant for all channel
plans and measurement modes.
Figure 219 Measure Mode – VoIP Telephone Number
21128026 R001 DSAM Help User Guide.book Page 242 Thursday, February 5, 2009 2:02 PM
