Page #336 background image
Appendix A Specifications
DSAM Product Family Series-1500, -2500, -2600, -3500, -3600, -6000 Specifications
296 DSAM Help User Guide Rev. 001
DSAM Product Family Series-1500, -2500, -2600, -3500,
-3600, -6000 Specifications
Table 47 Product Specifications
Item Description
Frequency
Range 4 to 1,000 MHz
Accuracy ±10 ppm at 25° C (77° F)
Tuning Resolution Analog 10 kHz
Digital 50 kHz
Channel Bandwidth Models ending in A, 8 MHz
Models ending in B, 6 MHz
Analog Level Measurement
Signal Types CW, video and audio
(NTSC, PAL, and SECAM)
Range
a
-40 to +60 dBmV (typical)
Resolution 0.1 dB
Resolution Bandwidth 280 kHz
Accuracy
b
± 1.5 dB typical at 25° C (77° F)
Digital Level Measurement
Modulation Types QPR, QPSK, QAM (DVB/ACTS)
Range
a
-40 to +50 dBmV (typical)
Resolution 0.1 dB
Resolution Bandwidth 280 kHz
Accuracy
b
± 2.0 dB typical at 25° C (77° F)
21128026 R001 DSAM Help User Guide.book Page 296 Thursday, February 5, 2009 2:02 PM
