JDS Uniphase DSAM-3600 User Manual

Chapter 9 Measure Mode – Service Tab
VoIP
DSAM Help User Guide Rev. 001 235
Configuring
DSAM for VoIP
Tests
To configure DSAM for VoIP tests
1 If necessary,
a adjust the Sounds parameters (“Configuring Sounds” on
page 30).
b select a channel plan with at least one DOCSIS channel
(“Choosing a Channel Plan” on page 78)
Running a VoIP
Test
To run a VoIP test
1 Press Measure.
2 Press the Service softkey.
3 Using the arrow keys, select VoIP.
4 Press ENTER.
NOTE
If no enabled downstream DOCSIS channels are available in the
channel plan during a VoIP Test, a warning is displayed to indicate
there is no DOCSIS channel enabled in the channel plan. Press the
OK softkey then select a downstream plan with at least one enabled
DOCSIS channel.
Figure 209 Measure Mode – Service Tab: VoIP
