Chapter 7 AutoTest Mode
AutoTests Tab
132 DSAM Help User Guide Rev. 001
DOCSIS Details View
To display the DOCSIS details view
1 From the DOCSIS summary view, use the arrow keys to highlight
the DOCSIS channel you wish to view.
2 Press the View softkey.
3 Using the arrow keys, select DOCSIS Details.
4 Press ENTER.
Registration View
To view registration detail for the selected channel
1 Using the arrow keys, select the channel you wish to view.
2 Press the View softkey.
3 Using the arrow keys, select Registration.
N
NOTE
To save the results to a file, press the Save softkey then follow
step 4 through step 13 under “Saving Results” on page 198.
Figure 125 AutoTest – Home Certification: DOCSIS Channel
Details
N
NOTE
To save the results to a file, press the Save softkey then follow
step 4 through step 13 under “Saving Results” on page 198.
