Chapter 4 Powering the DSAM
Powering the Meter
DSAM Help User Guide Rev. 001 25
For information about the charger module’s specifications, see
Table 48 on page 302.
Charging
Temperature
Range
Your DSAM Product Family Series charger module does not allow the
charge mode to begin if the battery temperature is not within a safe
range for charging. To begin and maintain the charge mode, the
battery temperature should be approximately between 0° C (32° F)
and 50° C (122° F). The charge mode automatically resumes when the
battery temperature returns within this range.
Table 12 High Capacity Charge LED Indications
LED color State Battery and charge condition
Red
(CHARGE)
Steady Charging
Flashing Charge fault check:
Temp too high/low or,
DC too high/low or,
Internal fault
Green (OK) Steady Charge Complete
21128026 R001 DSAM Help User Guide.book Page 25 Thursday, February 5, 2009 2:02 PM
