Chapter 3 Battery Installation
Installing and Maintaining the Standard Capacity Battery
DSAM Help User Guide Rev. 001 17
Connecting the
RF Cable
To conduct measurements with your DSAM Product Family Series,
connect the RF cable of the system you are servicing to the RF
connection port on the back panel of the meter.
Installing and Maintaining the Standard Capacity Battery
Installing the
Battery
To install the battery
1 Hold the meter securely with the display screen facing away from
you and the keypad in the palm of your hand.
2 Holding the battery in your other hand with its label facing away
from you, rest the lower (contact) edge of the battery against the
raised edge at the bottom of the meter.
3 Gently lower the battery into the cavity of the meter until the top
edge of the battery latches into place.
Removing the
Battery
To remove the battery
1 Hold the DSAM securely with the display screen facing away from
you and the keypad in the palm of your hand.
2 Press the release button located directly above the battery in the
center of the back of the meter.
3 Gently pull the battery out of the cavity.
Connecting the
Power
Components
(Standard
Capacity Battery)
In addition to the battery, the following power components are supplied
with the DSAM Product Family Series:
– Charger module
– Universal power supply module
– Power cord
– 12-volt DC in-vehicle power cable
NOTE
For information about optimizing battery life, refer to “Battery Con-
servation” on page 32.
21128026 R001 DSAM Help User Guide.book Page 17 Thursday, February 5, 2009 2:02 PM
