Chapter 5 Configuring the Meter
Configure – General Tab
52 DSAM Help User Guide Rev. 001
7 If the keypad fails to function properly, contact your JDS
Uniphase Corporation Customer Service Representative.
8 Press the Done softkey.
Using Virtual DSAM
To use Virtual DSAM
1 Connect an Ethernet cable to the DSAM.
2 Press Configure.
3 Press the General softkey.
4 Using the arrow keys, select Diagnostic.
5 Press ENTER.
6 Using the arrow keys, select Use Virtual DSAM.
7 Press the Select softkey.
Figure 41 Configure – Keypad Test
NOTE
During the test, the only keys that function normally are the Power
key and the Done softkey.
NOTE
In order to use Virtual DSAM, your computer and the Ethernet cable
must be connected to the same IP network or a public IP network.
21128026 R001 DSAM Help User Guide.book Page 52 Thursday, February 5, 2009 2:02 PM
