Chapter 3 Battery Installation
Installing and Maintaining the EZ Charge Battery
14 DSAM Help User Guide Rev. 001
Installing and Maintaining the EZ Charge Battery
Installing the
Battery
To install the battery
1 Hold the meter securely with the display screen facing away from
you and the keypad in the palm of your hand.
2 Holding the battery in your other hand with its label facing away
from you, rest the lower (contact) edge of the battery against the
raised edge at the bottom of the meter.
3 Gently lower the battery into the cavity of the meter until the top
edge of the battery latches into place.
Removing the
Battery
To remove the battery
1 Ensure the power is off.
2 Hold the meter securely with the display screen facing away from
you and the keypad in the palm of your hand.
3 Press the release button (Figure 9) located directly above the
battery in the center of the back of the meter.
CAUTION INSTRUMENT DAMAGE
Failure to turn the power off before removing the batteries from the
DSAM Product Family Series Complete DSAM Meter Functionality
could damage internal components and/or corrupt the software.
Always power down the unit before removing the batteries.
21128026 R001 DSAM Help User Guide.book Page 14 Thursday, February 5, 2009 2:02 PM
