Chapter 7 AutoTest Mode
AutoTests Tab
DSAM Help User Guide Rev. 001 145
Understanding Cable
Modem Test Results
Figure 136 AutoTest – DOCSIS AutoTest
NOTE
To save the results to a file, press the Save softkey then follow
step 4 through step 13 under “Saving Results” on page 198.
If you chose the wrong limit set before conducting the test, press
the Limits softkey and select a different limit set to view your test
results in relation to a different limit set without rerunning the test.
Figure 137 AutoTest – Video AutoTest Results
Table 44 DOCSIS AutoTest Results
Name Description
Overall Results This area displays the overall pass/fail results for
the test, the limit set applied (if applicable), and the
currently selected channel.
Overall Results
Overall Channel Results
Individual Test Results
21128026 R001 DSAM Help User Guide.book Page 145 Thursday, February 5, 2009 2:02 PM
