Chapter 9 Measure Mode – Service Tab
Ethernet
DSAM Help User Guide Rev. 001 229
1 Press the View softkey.
2 Using the arrow keys, select Ping.
3 Press ENTER.
4 Using the arrow keys, select the IP Address option.
5 Press ENTER.
6 Using the arrow keys, select the IP address you want to ping.
7 Press ENTER.
8 Using the arrow keys, select Packet Size (bytes).
9 Press ENTER.
10 Using the arrow keys, select the packet size you want to send.
11 Press ENTER.
12 Using the arrow keys, select the Time Between Pings option.
13 Press ENTER.
14 Using the arrow keys, select the time span between pings.
Figure 205 Measure Mode – Ethernet Ping Test
NOTE
To add, modify or delete an IP address, see “Adding Ping IP
Addresses” on page 231, “Modifying Ping IP Addresses” on
page 231 or “Deleting Ping IP Addresses” on page 232.
21128026 R001 DSAM Help User Guide.book Page 229 Thursday, February 5, 2009 2:02 PM
