Chapter 7 AutoTest Mode
AutoTests Tab
146 DSAM Help User Guide Rev. 001
Viewing Cable Modem
Results
DOCSIS Status View
To display the DOCSIS status view
1 Using the arrow keys, select the DOCSIS channel you wish to
view.
2 Press the View softkey.
3 Using the arrow keys, select DOCSIS Status.
4 Press ENTER.
The status of the DOCSIS channel is displayed.
Individual Test
Results
This area displays the results of individual tests for
the currently selected channel. When a measure-
ment falls outside the acceptable range, an arrow to
the right of the numeric value indicates the direction
in which the failure occurred. An up arrow indicates
a measurement over the limit range. A down arrow
indicates a measurement below the limit range.
Channel Results A symbol indicating whether the channel passed or
failed the overall test. When a measurement fails,
an arrow to the right of the numeric value indicates
the direction in which the failure occurred. An up
arrow indicates a measurement over the limit range.
A down arrow indicates a measurement below the
limit range.
Table 44 DOCSIS AutoTest Results (Continued)
Name Description
NOTE
Only valid measurements resulting from completed tests are dis-
played. When an error occurs prohibiting a valid measurement, a
dash indicates an invalid numeric value.
21128026 R001 DSAM Help User Guide.book Page 146 Thursday, February 5, 2009 2:02 PM
