Chapter 7 AutoTest Mode
AutoTests Tab
DSAM Help User Guide Rev. 001 143
2 Press AutoTest.
3 Using the arrow keys, select Cable Modem.
4 Press ENTER.
5 Using the arrow keys, select Channel Plan.
6 Press ENTER.
7 Using the arrow keys, select an option.
8 Press ENTER.
9 Using the arrow keys, select Limit Plan.
10 Press ENTER.
11 Using the arrow keys, select an option.
12 Press ENTER.
13 Using the arrow keys, select the following options.
– Edit Test Point Compensation – See page 71.
– Edit MAC Address – See page 65.
NOTE
The limit set parameters you set remain constant for all channel
plans and measurement modes.
NOTE
To perform the test without checking the results against limit values,
select Off.
If you select Off as the limit plan value, no pass/fail information is
available in the test results.
NOTE
Use “Regional Preferences” on page 43 to specify the type of signal
level units and digital performance units you prefer.
Use “Limit Sets” on page 58 to edit limit set parameters to meet
your needs.
Use “Other Settings” on page 65 to define the best measurement
settings (such as DOCSIS settings) for your current work practices.
21128026 R001 DSAM Help User Guide.book Page 143 Thursday, February 5, 2009 2:02 PM
