Appendix A Specifications
DSAM Product Family Series-1500, -2500, -2600, -3500, -3600, -6000 Specifications
300 DSAM Help User Guide Rev. 001
DSAM-3500, - 3600, and -6000 Additional Specifications
Downstream Spectrum (forward scan)
Frequency range 4 to 1000 MHz
Sweep rate Less than 2.5 seconds (display)
Display scaling and range 5 and 10 dB/division; 6 vertical
divisions
Resolution bandwidth 30 or 330 kHz
Span 10 MHz or 50 MHz
Sensitivity
a
-35 to 60 dBmV (typical)
Constellation (optional)
Modulation type 64, 128, and 256 QAM
Constellation points 2000, 4000, 8000, 16000, 32000, or
64000
Zoom up to 4 levels
Cable Modem Diagnostic Page
IP address
g
192.168.100.1
Return QAM Generator
Signal Modulations CW, 16 QAM, 64 QAM
Symbol Rates (MSPS) 1.28, 2.56, 3.84, 5.12
Frequency Range 5-55 MHz US, 5-65 MHz EURO
Supported Levels 8.0 - 58.0 dBmV
DSAM-6000 Sweep Specifications
Forward Sweep Requires SDA-5500
(SDA compatible mode)
Reverse Sweep and
Reverse Alignment
Requires SDA-5500 (Single Reverse)
or SDA-5510 (Multiple Reverse)
(SDA compatible mode)
Table 47 Product Specifications (Continued)
Item Description
21128026 R001 DSAM Help User Guide.book Page 300 Thursday, February 5, 2009 2:02 PM
