Program mode
14
V
3–1...5: FUNCTION
•0: Write Program, Write/Initialize Program see page 63
•1: Solo Setting see page 63
•2: Compare see page 64
•3: Auto Song Setup see page 64
•4: Add to Favorite see page 64
•5: Copy Oscillator see page 64
•6: Swap Oscillator see page 64
For more information, please see the “Program: Function” section
on page 63.
4: P–PITCH
This page contains all of the settings for Oscillator 1’s pitch
modulation.
4–1: BASIC
Here, you can:
• Specify pitch bend being controlled by the pitch bend wheel (or
an incoming pitch bend message) set to independent Bend Up
and Bend Down, or controlled by an incoming message CC#16
(the ribbon control message etc).
• Use Pitch Slope to control how the pitch changes when you
play up and down the keyboard.
• Assign AMS modulation for pitch.
OSC (Oscillator Select) [1, 2]
Select the oscillator (1 or 2) that you want to edit.
Note: Oscillator 2 can be selected if Oscillator Mode is set to
Double.
Octave [–2[32'], –1[16'], +0[8'], +1[4']]
This sets the basic pitch of the Oscillator, in octaves. The default is
+0[8']. The standard octave of a multisample is +0 [8'].
Transpose [–12...+12]
This adjusts the pitch in semitones, over a range of ±1 octave.
Tune [–1200...+1200]
This adjusts the pitch in cents, over a range of ±1 octave. A cent is
1/100 of a semitone.
Offset (Frequency Offset) [–10.0Hz ... +10Hz]
This adjusts the pitch by increments of 0.1 Hz. Frequency Offset
is different from Tune in that, when used to detune the two
oscillators, it can create a constant beat frequency across the range
of the keyboard.
CONTROLLERS
Bend (+) [–60...+12]
Specifies the amount of pitch change in semitone units that occurs
when you move the pitch bend wheel away from yourself (or when
a pitch bend message with a value of 1 or higher is received). For
normal pitch bend, set this to a positive value.
For example with a setting of +12, moving the pitch bend wheel
away from yourself will raise the pitch of the notes you've played,
by up to one octave.
