Single size effects 043: P4EQ - Exciter (Parametric 4-Band EQ - Exciter)
241
042: St. Ring Modulator (Stereo
Ring Modulator)
This effect creates a metallic sound by applying the oscillators to
the input signal. Use the LFO or Dynamic Modulation to modulate
the oscillator to create a radical modulation. Matching the
oscillator frequency with a note number will produce a ring
modulation effect in specific key ranges.
OSC Mode
This parameter determines whether or not the oscillator frequency
follows the note number.
Pre LPF
This parameter enables you to set the damping amount of the high
range sound input to the ring modulator. If the input sound
contains lots of harmonics, the effect may sound dirty. In this case,
cut a certain amount of high range.
Fixed Freq [Hz]
This parameter sets the oscillator frequency when “OSC Mode” is
set to Fixed.
Note Offset
Note Fine
These parameters for the oscillator are used when “OSC Mode” is
set to Note (Key Follow). The “Note Offset” sets the pitch
difference from the original note in semitone steps. The “Note
Fine” parameter fine-adjusts the pitch in cent steps. Matching the
oscillator frequency with the note number produces a ring
modulation effect in the correct key.
043: P4EQ - Exciter (Parametric 4-
Band EQ - Exciter)
This effect combines a mono four-band parametric equalizer and
an exciter.
Paramter Value Explanation
OSC Mode ←
Fixed, Note
Follow
Switching between
specifying the oscil-
lator frequency and
using a note number
p.241
Pre LPF ← 0...100
Sets the damping
amount of the high
range input to the
ring modulator p.241
Fixed[Hz]
Fixed Freq
[Hz]
0...12.0(k)
Sets the oscillator
frequency when OSC
Mode is set to Fixed
p.241
Src Source Off...Tempo
Selects the
modulation source
for the oscillator
frequency when OSC
Mode is set to Fixed
Amt Amount
–12.00k...
+12.00k
Sets the modulation
amount of the oscil-
lator frequency when
OSC Mode is set to
Fixed
NoteOffset Note Offset –48...+48
Sets the pitch
difference from the
original note when
OSC Mode is set to
Note (Key Follow)
p.241
Note Fine ← –100...+100
Fine-adjusts the oscil-
lator frequency p.241
LFO Depth ← 0...100
Sets the depth of LFO
modulation for the
oscillator frequency
Src Source Off...Tempo
Selects the
modulation source of
the depth of
modulation
Amt Amount –100...+100
Sets the modulation
amount of the depth
of modulation
LFO [Hz]
LFO Freq
[Hz]
0.02...20.00
Sets the speed of the
LFO p.226
Src Source Off...Tempo
Selects a modulation
source for LFO speed
Amt Amount
–20.00...
+20.00
Sets the modulation
amount of LFO speed
MIDI Sync
BPM/MIDI
Sync
Off, On
When this is on, the
LFO speed is set by
BPM, Base Note, and
Times, instead of
Frequency p.223
BPM ←
MIDI,
40.00...
300.00
MIDI syncs to the
system tempo; 40–
300 sets the tempo
manually for this
individual effect p.223
Base Note ← ...
Selects the type of
notes that specify the
LFO speed p.223
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Pre LPF
Ring Modulator
Pre LPF
Ring Modulator
Note No.
OSC Mode
Fixed
Note (Key Follow)
Fixed Frequency
Pitch
Note Offset, Fine
Sine Oscillator
LFO
Direct Mix
Times ← x1...x32
Sets the number of
notes that specify the
LFO speed p.223
Direct Mix ← 0...100
Direct signal (after
passing through the
pre-low-pass filter)
mixed into the ring
modulation output
Wet/Dry ←
Dry,
1 : 99...99 : 1,
Wet
Sets the balance
between the effect
and the dry input
Src Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amt Amount –100...+100
Sets the modulation
amount for Wet/Dry
Paramter Value Explanation
Parametric 4-Band EQ
E Trim Trim 0...100
Sets the parametric
EQ input level
E B1 F[Hz]
Band1
Cutoff [Hz]
20...1.00k
Sets the center
frequency of Band 1
Q Band1Q 0.5...10.0
Sets the bandwidth of
Band 1 p.221
Gain[dB]
Band1
Gain [dB]
–18...+18
Sets the gain of Band
1
E B2 F[Hz]
Band2
Cutoff [Hz]
50...5.00k
Sets the center
frequency of Band 2
Q
Band2
Cutoff [Hz]
0.5...10.0
Sets the bandwidth of
Band 2 p.221
Gain[dB]
Band2
Cutoff [Hz]
–18...+18
Sets the gain of Band 2
E B3 F[Hz]
Band3
Cutoff [Hz]
300...10.00k
Sets the center
frequency of Band 3
Q Band3 Q 0.5...10.0
Sets the bandwidth of
Band 3 p.221
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
Trim
+
Exciter
Parametric 4Band EQ Exciter
